RSS-3000 Electric Drop Beam

RSS-3000 Electric Drop Beam

The RSS-3000 Electric Drop Beam Barrier is a reliable vehicle access control solution designed for high-security perimeter protection. Available with beam widths ranging from 12 to 20 feet, it is well suited for commercial, industrial, government, and critical infrastructure facilities requiring dependable vehicle stopping capability.

Its above-ground hinge and receiver support design minimizes the need for extensive foundation excavation, making the RSS-3000 an excellent choice for sites with challenging ground conditions or locations where underground construction is limited. The rugged construction is built to perform in harsh weather and demanding operating environments while providing long-term durability.

The RSS-3000 has been independently crash tested to recognized industry standards, demonstrating its ability to stop high-impact vehicle threats and deliver dependable perimeter security. Barrier Stop Defense Consultants can help you choose the right drop beam barrier solution to meet your site’s specific security and operational requirements.

Call +1 602-489-4392

Description

The RSS-3000 is a heavy-duty crash-rated drop beam barrier designed for reliable vehicle access control and perimeter security. Its above-ground hinge and receiver system makes installation ideal for sites where roadway excavation is limited or prohibited. Built from hot-dip galvanized steel, the barrier provides excellent corrosion resistance and dependable performance in harsh weather conditions with minimal maintenance. Each unit is fully assembled and tested to ensure long-lasting reliability. The RSS-3000 is independently crash tested to recognized industry standards and can be integrated with push-button, touchscreen, and PLC-based control systems for efficient operation and seamless security management.

Clear Openings 12’–20’
Barrier Height (Top of Beam) 42in / 3.5ft / 1.07m
Certified Crash Rating ASTM M30, P1
Operating Speed Normal Operating Speed 7–10 seconds Emergency Fast Operation (EFO) Programmable
Duty Cycle 2,000 cycles per day, continuous
Motor Proprietary RSSI Servo Electromechanical Actuator. IP-67 rating, self-lubricating, and positive braking.
Power Requirements Single phase power: 208 or 240Vac w/neutral, 30A (handles 2 barriers)
Operating Temperatures -30° to 130° Fahrenheit (-34° to 54° Celsius)
Warranty The RSS-3000 series barrier is supported with a 1-year electrical and mechanical parts warranty when installed by a factory-trained contractor.
