Model 313, K4 Shallow Mount Bollard

Model 313, K4 Shallow Mount Bollard

The Model 313 K4 Shallow Mount Bollard is a high-performance crash-rated security solution designed to prevent unauthorized vehicle access while maintaining safe pedestrian movement. Its 9-inch shallow foundation allows for easier installation in areas with underground utilities or excavation restrictions.

Engineered for dependable perimeter protection, the Model 313 has been independently crash tested to recognized industry standards and provides strong vehicle impact resistance. Available in multiple configurations and finish options, it is an ideal choice for commercial, industrial, government, and critical infrastructure applications requiring reliable, space-efficient security.

Call +1 602-489-4392

Description

PRODUCT OVERVIEW – Shallow Mount Bollards

The Model 313 Shallow Mount Bollard is designed for projects that require high vehicle security with minimal excavation. Its shallow foundation makes it an excellent choice for sites with underground utilities, drainage systems, vents, grates, landscaping, or other surface obstacles. Custom layouts are available to meet unique site requirements, with bollard spacing engineered up to 60-inch centers.

The modular design allows for quick transportation, simplified installation, and fast on-site assembly without the need for specialized tools or welding, helping reduce installation time and labor costs.

Barrier Stop Defense Consultants provides expert support throughout every stage of your project, including product selection, system design, installation guidance, and ongoing maintenance. We also offer replacement parts, technical assistance, and extended warranty options to ensure long-term performance and reliability.

APPLICATIONS

The Model 313 is ideal for protecting high-security locations, including government buildings, military facilities, data centers, industrial sites, stadiums, petrochemical plants, utilities, and other critical infrastructure. Removable and deep-mount configurations are also available for projects with specific security or operational requirements.

FEATURES

  • Shallow 9-inch foundation for easier installation.

  • Crash-rated for dependable vehicle impact protection.

  • Adjustable leveling feet for accurate installation.

  • Fast modular assembly with no field welding required.

  • ADA-compliant spacing to support pedestrian access.

  • Available with painted, galvanized, or decorative sleeve finishes.

SPECIFICATIONS – Shallow Mount Bollards

  • Height: 40 inches

  • Diameter: 8.6 inches

  • Foundation Depth: 9 inches

  • Concrete Strength: 4,000 PSI

  • Standard Spacing: 42.7-inch centers

  • Crash Rating: K4/L3 (Certified)

  • Finish Options: Primer with paint or hot-dip galvanized

  • Decorative Sleeves: Stainless steel or aluminum

For pricing, product availability, or professional installation services, contact Barrier Stop Defense Consultants today.

Contact BarrierStop.com for pricing on availability for purchase and/or installation.
